Name: Full-Scale Tail Surface Drawings â Supplement to Aircraft Plans
Brand: Mini-Max USA
SKU: 5140FS
Price: 199.99 USD
Availability: InStock

Full-Scale Tail Surface Drawings â Supplement to Aircraft Plans

$199.99

Take the guesswork out of building. These full-scale tail surface drawings are designed to supplement your aircraft plans, giving you 1:1 scale templates for precise, confident construction.

Whether you're building a Mini-Max or another experimental aircraft, these sheets allow you to lay out parts directly on the drawing, trace components, and maintain critical alignments during your build.

Full-scale layout â perfect for placing materials directly on top
Ideal for builders of any experience level
Compatible with standard 1100-1700 plans (check all dimensions and holes against plans before drilling)
Professionally printed on large-format paper
Shipped rolled â never folded

Why Add This to Your Build?

✅ Save time measuring and scaling
✅ Eliminate build errors from misreading plans
✅ Confidence in alignment, angles, and control surface geometry
✅ Great for workshops with limited space for jigs

Select your Plans

All 4 Tail Surface Bundle

Fule Scale Horizontal Stabilizer

Full Scale Elevator

Full Scale Verticle Fin

Full Scale Rudder
