1650V V-Max Mini-Kits
Build your 1650V V-Max in stages. Choose one airframe section and the fabrication option available for that section. Each selection is a separate Mini-Kit purchase, not a complete aircraft kit.
1650V V-Max Mini-Kits
Build the VW-powered 1650V V-Max in modular stages. Mini-Kits let you build one section at a time, spread out cost, and move from plans to real airframe progress without buying the full kit all at once.
Wing Rib Kit Options
The Wing Rib Kit is different from the Wing Assembly Kit. The Wing Rib Kit covers the ribs. The Wing Assembly Kit covers spars, fittings, hardware, and wing structure components used to assemble the wing after the ribs are built.
- Raw Materials: materials and templates to build the wing ribs yourself.
- Laser Cut Gussets: a time-saving rib kit option with laser cut gussets.
- Prebuilt Wing Ribs: prebuilt wing ribs for builders who want to save time on one of the most repetitive parts of the wing build.
Mini-Kit Pricing
Pricing is based on ideal retail value with no waste, then discounted 10% for the Mini-Kit buying path.
Important
Mini-Kits are aircraft components and materials, not completed aircraft. Engine, propeller, covering, paint, instruments, avionics, inspection, registration, certification, training, and assembly labor are separate unless specifically listed.
Choose your section and version
The Wing Rib Kit and Wing Assembly Kit are separate purchases. Select the matching section and version before adding it to your cart.
| Section / version | Part number |
|---|---|
| Wing Rib Kit / Raw Materials | 5105 |
| Wing Rib Kit / Laser Cut Gussets | 5105LC |
| Wing Rib Kit / Prebuilt Wing Ribs | 5105PF |
| Wing Assembly Kit / Standard | 5110V |
| Fuselage Kit / Standard | 5615V |
| Landing Gear Kit / Standard | 5520V |
| Empennage Kit / Standard | 5525V |
| Metal & Hardware Kit / Standard | 5630E |
| Metal & Hardware Kit / Prebuilt Metal Parts | 5630EPF |
The displayed price is for the selected option. A collection price marked “from” is the lowest-priced individual section, not the total cost of all sections.
View matching plans · Compare the full airframe kit · Compare aircraft models
Other ways to start your 1650V
Buy Plans
Start with the plans
$299.99
Model-specific plans, shipped to you. Shipping is added at checkout.
Buy 1650V plans-
Build in Stages
Mini-Kits, one section at a time
Mini-Kits from $819.99
Wing, fuselage, tail, landing gear and hardware as separate kits. Each is paid in full when you order it and may not include every item needed to complete the aircraft.
Shop 1650V Mini-Kits -
Buy a Complete Kit
The whole airframe, one order
Complete kit from $13,499.99
Base, prefab wing ribs, or prefab ribs and metal parts. Crating and shipping are added at checkout.
Shop 1650V complete kit -
Aircraft Kit Layaway
Pay for a complete kit over time
Payments from /month
monthly payments after due at signing (down payment plus crating).
See your layaway payment Ask about layawaySpread a complete kit over 12 to 36 months. Contact us for current layaway pricing on the 1650V.
Layaway is not financing and not a loan. Kit sections are released in stages as your cleared payments reach each release threshold, and the complete kit ships only after your final payment. Shipping, taxes and options are extra. Read the layaway terms.
Buy the plans first? Buy the same model's full kit, or pay its layaway down payment, within 60 days and we credit the price you paid for the plans. Request the credit before you pay for the kit.
Layaway for the 1650V
a month for payments
- Complete-kit cash price ()
- Layaway kit price
- Due at signing (% down + crating)
- Total program cost
Layaway is not a loan or financing. Prefab / Quick-Build is the level with prefab wing ribs and prefab metal parts; the prefab-ribs-only level is not offered on layaway. Add-on options, shipping, freight and taxes are extra, and final figures are confirmed on your invoice and contract.
Layaway lets you pay for a complete kit over 12 to 36 months while sections are released in stages. It is not financing. Contact us for current layaway pricing on this model.
Ask about layawaySpecifications+
Aircraft Specifications
- Wing Layout: Mid-wing
- Cockpit: Enclosed
- Wingspan: 26' 6"
- Wing Area: 118 SQ. FT.
- Height: 60"
- Length: 16'
- Cockpit Width: 24"
Weights
- Empty Weight: 400 LBS
- Useful Load: 300 LBS
- Max Gross Weight: 700 LBS
- Wing Loading @ Gross: 5.93 LBS/SQ. FT.
- Power Loading @ Gross: 14.0 LBS/HP
Powerplant
- Reference Horsepower: 50 HP
- Engine Options: VW 50HP
- Fuel Capacity: 6.5G Standard 13G Optional
Performance
- Top Speed: 80 MPH
- Cruise Speed: 75 MPH
- Stall Speed (Clean): 39 MPH
- Stall Speed (Flaps): 34 MPH
- Climb Rate: 900 FPM
- VNE: 110 MPH
- Takeoff (Grass): 150 FT
- Landing Roll (Grass): 250 FT
Build Information
- Base Kit Build Time: 325-400 Hours
- Prefab Kit Build Time: 250-300 Hours
Figures reflect the 50 hp VW reference configuration and track closely to the 1550V pending model-specific validation.
Features (Standard / Optional)
- Flaperons: Optional
- Wheel Pants: Optional
- Wing Tips: STANDARD
- Steel Gear: Optional
- Band Brakes: Optional
- Black-Max Brakes: Optional
What's Included+
Mini-Kits let you stage your 1650V V-Max build and spread out cost — order the airframe sections you need and move from plans to real airframe progress without buying a full kit all at once.
- Order individual airframe sections (for example wing rib kits and wing assembly kits).
- Choose the material level where offered — raw materials, laser-cut gussets, or prebuilt wing ribs.
- Combine sections over time to complete the airframe at your own pace.
Not included unless listed
Engine, propeller, instruments, avionics, battery, wiring, covering, paint, upholstery, shipping, assembly labor, registration, certification, inspection, and training are not included unless the product page or invoice specifically says so.
Build Time & Skill Level+
Estimated build time depends on the kit level you choose and your experience. Prefab wing ribs and prefab metal parts meaningfully reduce build time.
- Base kit build time: 325-400 Hours
- Prefab quick-build kit build time: 250-300 Hours
This is an amateur-built, wood-and-fabric aircraft designed for hands-on homebuilders. Typical skills:
- Basic woodworking, measuring, and drilling
- Riveting and assembly of metal parts
- Epoxy work and fabric covering
- No welding or advanced machining required for a standard build
Mini-Max USA builder-assist support is available to help you finish.
Part 103 & Experimental+
The 1650V V-Max is typically completed and licensed as an Experimental Amateur-Built (E-AB) aircraft. Under the FAA 'major portion' (51%) rule, a homebuilt aircraft you build for education and recreation can receive a special airworthiness certificate in the Experimental Amateur-Built category.
- N-number registration and an airworthiness inspection are required before first flight.
- The builder of the major portion may apply for a Repairman Certificate for that aircraft.
- May be flown by Sport Pilot or Private Pilot certificate holders, depending on the aircraft and pilot.
- A low-cost, wood-and-fabric homebuilt — a practical way to build and fly your own airplane and accumulate flight time affordably.
Final category, eligibility, and operating limitations depend on your build, documentation, inspection results, and applicable regulations. You are responsible for registration, certification, and legal operation. No listing statement is an FAA determination.
